SkyLink TOC BOX
Services: Iridium Certus® 100
-
SkyLink Certus 100 voice & data
-
All-in-one communications kit
-
Ruggedized case
-
Wi-Fi access
-
Internet/VPN
SkyLink TOC BOX
Manufacturer : Blue Sky Network, LLC
Model : SL100-TOCBOX-H
Services: Iridium Certus® 100
-
SkyLink Certus 100 voice & data
-
All-in-one communications kit
-
Ruggedized case
-
Wi-Fi access
-
Internet/VPN
Portability for Mission-Critical Voice and Data Connectivity
The SkyLink TOC BOX delivers mission-critical communications from any location on the planet, with the added protection of a ruggedized case. This compact and versatile communications terminal is powered by Iridium Certus®, providing enterprise-grade voice and mid-band data.
Product Specifications and Certifications
| Mechanical | |
|---|---|
| Dimensions (L x W x H) | 502mm x 390mm x 190mm |
| Weight | 1080 g |
| Iridium Embedded Technology | Iridium Certus 9770 Module |
| Environmental | |
| Operating Temperature Range | -40 to +70 excluding batteries, -20 to +55 including batteries ℃ |
| Ingress Protection | IP67 |
| Antenna | |
| Antenna Design | Maruwa and LTE antennas |
| Battery | |
| Capacity | 13333 mAh |
| Power | |
| Power Supply | 2x +14.4VDC lithium batteries or +12VDC vehicle input |
| Maximal Power | 18 W |
| Idle Power | 7 W |
| Network | |
| Satellite Coverage | Iridium Certus |
| Additional Networks | 4G/LTE |
| Telephony | 2x high quality voice channels |
| Laptop Compatibility | Any |
| Data Speeds | |
| Data Speed Uplink (UL) | 22 Kbps |
| Data Speed Downlink (DL) | 88 Kbps |
| Wi-Fi | |
| Wi-Fi Enabled | Yes |
| User Experience | |
| Mobility | Smart device support |
