SkyLink 5100 for Land-Based Solutions


  • Dual-Mode Connectivity with Least-Cost Routing
  • Internet/VPN Access with Wi-Fi Hotspot and Dynamic Firewall
  • Email and Media Sharing
  • Two (2) HD Analog Voice Lines and VOIP Push-to-Talk (PTT)
  • GPS Position Tracking

Land-Based Voice
and IP Data Solution

The SkyLink 5100 by Blue Sky Network delivers next-generation satellite connectivity to any location on the planet. This compact and versatile communications terminal is powered by the truly global Iridium® network, providing enterprise-grade voice, remote monitoring, and data connection.

As a certified Iridium Connected® product, the SkyLink 5100 is designed for complete business efficiency, safety and continuity coverage. Its slim design allows for easy mounting on fixed or mobile units to transfer real-time data from existing sensors, asset utilization and IoT/M2M monitoring tools. In the field, use this device as a portable communications and media sharing platform for mission-critical updates to and from remote and frontline workers. With the SkyLink 5100, achieve total connectivity for all assets, in every location, across the globe.

Features

  • Iridium Certus® 100 Services
  • Cellular LTE, 3G, 4G
  • Least-cost Routing
  • GNSS Positioning
  • Wi-Fi and Bluetooth
  • Local Dynamic Firewall
  • Two (2) Iridium Voice Lines
  • Push-to-Talk
Skylink Product Image

Product Specifications and Certifications

Technical Specifications

Mechanical
Field Label Field Value
Dimensions ( L x W x H ) 203 x 127 x 32 mm
Weight 450 g
Iridium Embedded Technology Iridium Certus 9770 Module
Environmental
Field Label Field Value
Operating Temperature Range -40 to +70 ℃
Operating Humidity Range ≤ 75% % RH
Storage Temperature Range -40 to +85 ℃
Storage Humidity Range ≤ 93% % RH
Ingress Protection IP65
Power
Field Label Field Value
Input Voltage Range 10 – 34 VDC
Network
Field Label Field Value
Additional Networks Cellular LTE, 3G, 4G
Location Based Services GNSS Positioning
Wi-Fi
Field Label Field Value
Wi-Fi Enabled Yes
User Experience
Field Label Field Value
Mobility Portable or Installed
