SkyLink 7100 (Aviation)

Manufacturer : Blue Sky Network, LLC

Model : 7100

  • BVLOS Communications
  • Command and Control
  • Communications Backhaul
  • GNSS Positioning
  • LIDAR Compatibility
Product photo of Iridium Connected Skylink 7100-Aviation for Iridium Certus 100
Product photo of Iridium Connected Skylink 7100-Aviation for Iridium Certus 100
Product photo of Iridium Connected Skylink 7100-Aviation for Iridium Certus 100
Product photo of Iridium Connected Skylink 7100-Aviation for Iridium Certus 100

SkyLink 7100 (Aviation)


Manufacturer : Blue Sky Network, LLC

Model : 7100

  • BVLOS Communications
  • Command and Control
  • Communications Backhaul
  • GNSS Positioning
  • LIDAR Compatibility

UAV IP Datalink Solution

SkyLink 7100 by Blue Sky Network delivers next-generation, global satellite connectivity to support autonomous communications and data monitoring beyond visual line of sight (BVLOS). The compact and versatile communications terminal is powered by the Iridium Certus® 100 midband service, enabling enterprise-grade IP throughput from a constellation of 66 cross-linked satellites for truly global connectivity.

As a certified Iridium Connected® solution, SkyLink 7100 is a mid-band transceiver designed for complete operational efficiency, safety, and continuity coverage. Its slim design allows for easy integration and installation on UAVs to stream low latency data from onboard sensors, transfer photos, and utilize real-time command and control. With SkyLink 7100, achieve total connectivity for all assets, in every location, across the globe.

Capabilities

  • Least-Cost Routing
  • Ethernet, USB, RS232
  • GNSS Positioning/Tracking
  • Application Hosting
  • Remote Device Management
  • Data Analytics and Edge Computing
  • Diagnostics and Health Monitoring
  • Iridium Certus® 100 Services
  • Cellular LTE CAT 6: 300 Mbps DL / 50 Mbp
  • Remote Monitoring & Surveillance

Product Specifications and Certifications

Technical Specifications

SkyLink 7100 (Aviation)
Mechanical
Dimensions (L x W x H) 203mm x 127mm x 32mm
Weight 730 g
Iridium Embedded Technology Iridium Certus 9770 Module
SkyLink 7100 (Aviation)
Environmental
Operating Temperature Range -40 to +70 ℃
Operating Humidity Range ≤ 75% % RH
Storage Temperature Range -40 to +85 ℃
Storage Humidity Range ≤ 93% % RH
Ingress Protection IP65
SkyLink 7100 (Aviation)
Power
Input Voltage Range 10 – 34 VDC
SkyLink 7100 (Aviation)
Network
Additional Networks Cellular LTE, 3G, 4G
Location Based Services GNSS Positioning
SkyLink 7100 (Aviation)
Wi-Fi
Wi-Fi Enabled Yes
SkyLink 7100 (Aviation)
User Experience
Mobility Portable or Installed
