SatStation EdgeMate - Controller/Router/Interface Solution for Iridium Edge®

Manufacturer : SatStation

Model : AP7632-EC1

    • Allows Ethernet and WiFi connectivity to the Irdium Edge®.
    • No software development necessary.
    • Simple API for developers wanting to create SBD applications.
    • Least Cost Routing included to help developers wishing to reduce cost when in LTE coverage areas.
    • CAN bus connections available to interface with vehicular or NMEA2000 networks.
    • Powerful firewall with intelligent routing that can be used with Least Cost Routing.
    • Remote support access features built-in.

SatStation EdgeMate - Controller/Router/Interface Solution for Iridium Edge®


Manufacturer : SatStation

Model : AP7632-EC1

    • Allows Ethernet and WiFi connectivity to the Irdium Edge®.
    • No software development necessary.
    • Simple API for developers wanting to create SBD applications.
    • Least Cost Routing included to help developers wishing to reduce cost when in LTE coverage areas.
    • CAN bus connections available to interface with vehicular or NMEA2000 networks.
    • Powerful firewall with intelligent routing that can be used with Least Cost Routing.
    • Remote support access features built-in.



  • Allows Ethernet and WiFi connectivity to the Irdium Edge®.
  • No software development necessary.
  • Simple API for developers wanting to create SBD applications.
  • Least Cost Routing included to help developers wishing to reduce cost when in LTE coverage areas.
  • CAN bus connections available to interface with vehicular or NMEA2000 networks.
  • Powerful firewall with intelligent routing that can be used with Least Cost Routing.
  • Remote support access features built-in.
  • Ethernet/Wi-Fi Connectivity
  • The Iridium Edge® has a proprietary serial port as the only external interface.  EdgeMate allows for both ethernet and Wi-Fi connectivity to the Iridium Edge.  This allows modern day computers, tablets, smartphones, and other devices that don’t have serial ports to communicate on Iridium’s network via the Iridium Edge®.  The EdgeMate enables any device with Wi-Fi or ethernet to send and receive Iridium SBD through the Iridium Edge®.

  • No Need for Software Development
  • No software development skills are required to use the Iridium Edge® when paired with an EdgeMate.  The Edge Mate comes with the following built-in applications that can be easily access with any web browser.

    EdgeMate is preconfigured for the following Tracking and Reporting Platforms:

    • GSatTrack
    • Nova GAP

    The Network Share feature allows a user to easily drop in files from their computer to send over Iridium SBD and receive inbound SBD files.

    The Web Form allows the user to type in messages and/or upload files to be sent over Iridium SBD

    The System Log offers the user a running report of all internal and external processing done by the EdgeMate.

  • Simple API
  • EdgeMate includes a simple API interface allowing developers wanting to create their own SBD applications to access all of the features of the Edge without having to develop special cables or hardware.

  • Least Cost Routing
  • EdgeMate comes with built in LTE modem that can be used to send data inexpensively in areas with LTE coverage.  It can be set to prioritize LTE and to fail over to Iridium SBD when no LTE data is available.   The EdgeMate can be set up to use LTE with SBD failover, LTE only or SBD only.   This least cost routing capability allows users to reduce data cost when their asset is in an LTE coverage area.

  • CAN Bus
  • EdgeMate comes with 2 CAN buses that can be used to interface to vehicular networks and/or marine NMEA2000 instrumentation networks.

  • Firewall
  • EdgeMate has a powerful built-in firewall with intelligent routing that allows users to create profiles based on the active wide area network (Iridium or LTE) and the type of local connection (Wi-Fi, Ethernet, CAN Bus, USB).

  • Remote Access
  • Remote support access can be provided to techs to diagnose problems on the Mate and other devices connected to the Mates internal network.  This can be accomplished via a number of internet connected methods including the on site techs mobile phone via either WiFi or USB tethering.

  • And More!
  • In addition to all of the above connectivity and interface options, EdgeMate can be further customized to meet specific applications.  EdgeMate runs on a powerful embedded Linux platform that can easily be used to develop and extend its functionality.

Product Specifications and Certifications

Technical Specifications

Mechanical
Dimensions (L x W x H) 8mm x 6mm x 2mm
Weight 19 g
Environmental
Operating Temperature Range -10°F to +140°F ℃
Operating Humidity Range 95 % RH
Vibration Standard 10 to 55Hz with 1.5mm amplitude 2 hours
Power
Power Supply 9-60V DC with polarity protection 2A peak power consumption
Memory
Ram 256 MB
Flash 32 MB
Storage 1 GB
