Guardian Mobility G4MX2

Manufacturer : Guardian Mobility Inc.

Model : G4-IC-ME-EX

  • Enhanced areal firefighting capability (ATU)

  • Additional I/O’s and sensor management

  • Dual mode satellite/cellular

  • AFF & text messaging via free app

Guardian Mobility G4MX2


Manufacturer : Guardian Mobility Inc.

Model : G4-IC-ME-EX

  • Enhanced areal firefighting capability (ATU)

  • Additional I/O’s and sensor management

  • Dual mode satellite/cellular

  • AFF & text messaging via free app

Aerial Firefighting

The G4MX2 solution provides a complete end-to-end system supporting ATU, AFF, text messaging and more. Both ATU and AFF reports received by GMI are automatically sent to U.S. government agencies using the government mandated protocols. The G4MX2 solution provides the same data tracking, messaging and alerting features as the G4C, but is designed as a fixed installation to aircraft. In addition to multiple digital inputs, the G4MX2 offers analogue inputs which allows the ATU to offer specialized aerial firefighting capabilities that meet international standards.

GMI makes it easy for our customers to meet the ATU and AFF requirements.

Features

G4MX2 offers reliable tracking, messaging & alerting for firefighting applications.
Providing the same seamless coverage, tracking and communication as our G4 solution with additional features for aerial firefighting operations.

  • Enhanced aerial firefighting capability
  • Multiple interfaces
  • World-wide coverage
  • All-in-one box – robust enclosure
  • Additional I/O’s and sensor management
  • Emergency notifications and POI
  • Text messaging via free app
  • Last message after loss of power
  • Field firmware upgradable
  • Dual mode satellite/cellular

Product Specifications and Certifications

Technical Specifications

Mechanical
Dimensions (L x W x H) 150mm x 100mm
Dimensions ( H x Ø ) 33mm
Weight 350 g
Iridium Embedded Technology Iridium 9603 Module
Environmental
Operating Temperature Range -20 to +55 ℃
Storage Temperature Range -40 to +80 ℃
Antenna
Antenna Design External Antenna's
Type Cell, Sat, GPS, BT
Power
Input Voltage Range 9V - 28VDC

Guardian Mobility G4MX2

G4MX2 offers reliable tracking, messaging & alerting for firefighting applications.
Providing the same seamless coverage, tracking and communication as our G4 solution with additional features for aerial firefighting operations.
