Guardian Mobility G4MX2
Services: Iridium Short Burst Data® (SBD®)
-
Enhanced areal firefighting capability (ATU)
-
Additional I/O’s and sensor management
-
Dual mode satellite/cellular
-
AFF & text messaging via free app
Guardian Mobility G4MX2
Manufacturer : Guardian Mobility Inc.
Model : G4-IC-ME-EX
Services: Iridium Short Burst Data® (SBD®)
-
Enhanced areal firefighting capability (ATU)
-
Additional I/O’s and sensor management
-
Dual mode satellite/cellular
-
AFF & text messaging via free app
Aerial Firefighting
The G4MX2 solution provides a complete end-to-end system supporting ATU, AFF, text messaging and more. Both ATU and AFF reports received by GMI are automatically sent to U.S. government agencies using the government mandated protocols. The G4MX2 solution provides the same data tracking, messaging and alerting features as the G4C, but is designed as a fixed installation to aircraft. In addition to multiple digital inputs, the G4MX2 offers analogue inputs which allows the ATU to offer specialized aerial firefighting capabilities that meet international standards.
GMI makes it easy for our customers to meet the ATU and AFF requirements.
Features
G4MX2 offers reliable tracking, messaging & alerting for firefighting applications.
Providing the same seamless coverage, tracking and communication as our G4 solution with additional features for aerial firefighting operations.
- Enhanced aerial firefighting capability
- Multiple interfaces
- World-wide coverage
- All-in-one box – robust enclosure
- Additional I/O’s and sensor management
- Emergency notifications and POI
- Text messaging via free app
- Last message after loss of power
- Field firmware upgradable
- Dual mode satellite/cellular
Product Specifications and Certifications
Mechanical | |
---|---|
Dimensions (L x W x H) | 150mm x 100mm |
Dimensions ( H x Ø ) | 33mm |
Weight | 350 g |
Iridium Embedded Technology | Iridium 9603 Module |
Environmental | |
Operating Temperature Range | -20 to +55 ℃ |
Storage Temperature Range | -40 to +80 ℃ |
Antenna | |
Antenna Design | External Antenna's |
Type | Cell, Sat, GPS, BT |
Power | |
Input Voltage Range | 9V - 28VDC |
