Urb-IoT: Outdoor Edge Gateway + Network Server

Manufacturer : Urbit Group LLC

Model : Urb-IoT

  • Global Connectivity: Wi-Fi, Cellular and Iridium® Satellite
  • Edge Computing: Manages Data Locally to Reduce Data Transmission, Cloud Processing and Storage
  • Cloud Connectivity: Your Data is Secure and Accessible Globally
  • Plug and play: Easy Installation and Ready to Deploy Outdoor, IP68 Rating
  • Feature-Rich: Connects Multiple End Devices Via LoRaWAN, Wi-Fi and/or BLE

Urb-IoT: Outdoor Edge Gateway + Network Server


Manufacturer : Urbit Group LLC

Model : Urb-IoT

  • Global Connectivity: Wi-Fi, Cellular and Iridium® Satellite
  • Edge Computing: Manages Data Locally to Reduce Data Transmission, Cloud Processing and Storage
  • Cloud Connectivity: Your Data is Secure and Accessible Globally
  • Plug and play: Easy Installation and Ready to Deploy Outdoor, IP68 Rating
  • Feature-Rich: Connects Multiple End Devices Via LoRaWAN, Wi-Fi and/or BLE

Edge Computing
and Global Connectivity

Urn-IoT is a hybrid gateway that enables flexible and scalable deployment of LoRaWAN, BLE and Wi-Fi IoT objects. It offers a global, reliable IoT connectivity by combining Wi-Fi, Global Cellular and Iridium® Satellite networks.

The Urb-IoT allows real-time monitoring and GPS tracking of assets either on land or sea.

Flexible and Scalable Deployment

IoT provides businesses better insight into and control over the objects and environments that previously were not connected to the Internet. The number of connected devices is overwhelmingly increasing, but there are still many regions in the world, which still don’t have any access to the Internet

  • Multiple Backhaul Connectivity
  • Global pole-to-pole connectivity (Wi-Fi, Cellular and Iridium's satellite L-Band)
  • Installation and Configuration
  • Easy and immediate installation and configuration, maintenance free. IP68 Rating
  • Edge Processing
  • Manages data locally to reduce data transmission, cloud processing and storage
  • API Integration
  • Integrate data into IoT App and analytic platforms via API
  • Cloud Connectivity
  • Your data is secure and accessible globally
  • Battery
  • Long-lasting battery and multiple power supply options

Product Specifications and Certifications

Technical Specifications

Environmental
Field Label Field Value
Operating Temperature Range -40 to +70 ℃
Storage Temperature Range -50 to +85 ℃
Ingress Protection IP68
Antenna
Field Label Field Value
Type Internal Ceramic
Polarization RHCP
Maximum Gain 5.1 dBi
GPS
Field Label Field Value
GPS TTFF Warm and Cold: <60 s
Battery
Field Label Field Value
Capacity 20100 mAh
Battery Life, Standy 72 hr
Charge Time 20 hr
Power
Field Label Field Value
Li-ion battery
Input Voltage Range 100-240V AC
Maximal Current 2500 mA
Maximal Power 13 W
Load Dump Input line fuse protection and Dielectric Withstand Voltage: 4000Vac or 5656Vdc 10mA 1 minute
Network
Field Label Field Value
Satellite
Satellite Coverage Pole to Pole
Additional Networks Dual Mode LTE-M/NB-IoT
Wi-Fi
Field Label Field Value
Wi-Fi Enabled Yes
Frequency Range 2.4 GHz

Urb-IoT: Outdoor Edge Gateway + Network Server

IoT provides businesses better insight into and control over the objects and environments that previously were not connected to the Internet. The number of connected devices is overwhelmingly increasing, but there are still many regions in the world, which still don’t have any access to the Internet
