RuggON PX501 Rugged Tablet

Manufacturer : Ubiqconn Technology (USA) Inc.

Model : PX501

  • 13th-generation Intel® Core™ i5, i7 processors

  • Advanced display with high brightness & hyper dimming technology to adapt different light conditions

  • WiFi 6E & 5G supported

  • Hot-swap battery & fast charging offers near indefinite capacity

  • A wealth of I/O ports and expansion options fulfill field use

RuggON PX501 Rugged Tablet


Manufacturer : Ubiqconn Technology (USA) Inc.

Model : PX501

  • 13th-generation Intel® Core™ i5, i7 processors

  • Advanced display with high brightness & hyper dimming technology to adapt different light conditions

  • WiFi 6E & 5G supported

  • Hot-swap battery & fast charging offers near indefinite capacity

  • A wealth of I/O ports and expansion options fulfill field use

Rugged Tablet With Massive Performance & Technology Upgrades

Long one of the industry’s most solid Tier 1 tablet computers, the Windows-based PX501 platform has been upgraded. With multi-generation processing and communication technologies updates–to include Iridium® connectivity–there’s a lot more power and purpose under the hood.

This unit is a multitasker—at home in numerous applications, including: law enforcement, field services, fleet, agriculture, military, automotive, logistics, manufacturing, unmanned vehicle control, and device customization.

Features

  • Beyond The Touch
  • Integrated with advanced touch technology, PX501 can avoid unintended touches including hand palm, water mist, and rain drops while ensuring correct data and command input. Paired with IP54 digitizer pen or 2mm hard tip stylus, the PX501 ensures accurate touchscreen interaction and sensible writing experience. Combined with the hard Gorilla Glass and glove touch function PX501 is truly a dedicated device for mobile workers to resist external damage and fulfill field needs.

  • Enhanced Visibility
  • PX501 is purpose-built for mobile workers to perform tasks from day to night. This device provides optimal visibility in all ambient light conditions, thanks to the 1000 nits high brightness display and hyper dimming technology.

  • Unlimited Connectivity
  • With uncompromising ruggedness, PX501 comes with a wealth of I/O ports and expansion options to meet various requirements of different applications. The tablet’s fingerprint reader, smart card reader, MRZ reader, and integrated 2D barcode reader with optional OCR capabilities allow for passport scanning and identity detection, while its snap-on connector is also easy to customize.

  • A Perfect Link: Anytime, Anywhere
  • Equipped with the latest and complete communication technology, mobile workers can experience precise positioning, faster processing, broader coverage and more stable data transfer even around buildings or trees. The seamless connection will be enhanced through switchable dual pass-through connector.

Product Specifications and Certifications

Technical Specifications

Mechanical
Iridium Embedded Technology Iridium 9603 Module
General
System Intel® Core™ i5-1335UE, Intel® Core™ i7-1365UE, Intel® Processor U300E, 8GB DDR5 SDRAM , optional 16/32GB DDR5 SDRAM, 128GB PCIE M.2 SSD, optional 256GB/512GB/1TB PCIE M.2 SSD, OS supports Windows 11 GAC
Durability IP65, MIL-STD-810H and MIL-STD-461G certified, Vibration, shock and 5' drop resistance, Operating temperature : -20° C to +60° C
Display 10.1” TFT LCD WUXGA (1920 x 1200), Gorilla Glass 1000 nits sunlight readable with hyper dimming option, Capacitive multi-touch screen supports glove touch, water rejection, 2mm hard tip stylus Optional digitizer with IP54 pen
I/O USB 3.1 type A x 1, USB 3.2 Gen 2 Type-C w/ DP & PD x 1, RS-232 x 1, option USB 2.0 or Micro SD slot, Gigabit Ethernet (RJ45) x 1, Audio headset jack x 1, Nano SIM slot x 2, Optional RF pass-through connector for WLAN/ GNSS/ WWAN x 2, Docking connector x 1 DC-in x 1
Expansion Options Built-in 2D barcode reader (OCR option), NFC + Smart Card reader 2-in-1 module, Fingerprint reader, MRZ reader Snap-on connector, easy for customization
Communications Iridium Connected, Wi-Fi 6E (802.11ax), Bluetooth V5.3, GNSS (GPS/ GLONASS/ BeiDou), Optional 4G LTE/ 5G (Sub-6G)
Camera 2MP front camera, 8MP auto focus rear camera with LED flash
Power AC adapter (65W, 100-240V AC, 50/60Hz), 4500mAh hot-swappable Li-ion battery, optional 9000mAh hot-swappable Li-ion battery, Supports fast charging
Security TPM2.0

Certifications

  • Iridium® Certification
  • IP65
  • MIL-STD-810H
  • MIL-STD-461G
