HXDC 1610-SAA - External Iridium Antenna - SMA Connector

Manufacturer : Helix Technologies Limited

Model : HXDC 1610-SAA

  • Iridium frequency: 1,616 – 1,626 MHz

  • IP67 rated

  • Immune to out-of-band interference

  • Bulk discounts over 5 units (visit Helix Geospace for more information)

HXDC 1610-SAA - External Iridium Antenna - SMA Connector


Manufacturer : Helix Technologies Limited

Model : HXDC 1610-SAA

  • Iridium frequency: 1,616 – 1,626 MHz

  • IP67 rated

  • Immune to out-of-band interference

  • Bulk discounts over 5 units (visit Helix Geospace for more information)

Resilient. Rugged.

The HXDC1610-SAA is a high-performance antenna created for the Iridium® Network built upon DielectriX™ technology. Helix’s Iridium antennas feature exceptional multi-path (reflected) signal selectivity and are resistant to RF and electrical noise. They’re balanced and isolated from platform ground, so they’re immune to common-mode noise. They’re also unaffected by nearfield object de-tuning.

HXDC1610-SAA Features

  • Applications
    • Defense, security, CNI, first responder
    • Asset & fleet vehicle tracking
    • Industrial, oil & gas, mining
    • View more applications
  • Small, Over-Molded Antenna
    • 50.5mm long x 19mm dia. (with SMA connector)
    • IP67 rated

Product Specifications and Certifications

Technical Specifications

Mechanical
Dimensions (L x W x H) 50.5mm
Dimensions ( H x Ø ) 19mm
Weight 26 g
Environmental
Operating Temperature Range -40 - +85 ℃
Antenna
Polarization RHCP
RF Interface
Frequency Range 1,616-1,626 MHz
I / O Impedence 50 Ohm
