Beam Grab & Go Corded Kit for Iridium Extreme® PTT
Manufacturer : Beam Communications
Model : PTTGNG-C1
Services: Iridium Push-To-Talk | Voice Calling | Iridium Circuit Switched Data (CSD) | Iridium Short Burst Data® (SBD®)
-
Iridium Push-to-Talk in a Fully Transportable Case
-
Low Profile Dual-Mode Mag Antenna with 5m of Cable
-
Dedicated & Durable Corded Fist Mic
-
Standard DriveDock, so Can Support Iridium Extreme in Standard Voice Mode
-
Rugged, Easy-to-Carry Case
Beam Grab & Go Corded Kit for Iridium Extreme® PTT
Manufacturer : Beam Communications
Model : PTTGNG-C1
Services: Iridium Push-To-Talk | Voice Calling | Iridium Circuit Switched Data (CSD) | Iridium Short Burst Data® (SBD®)
-
Iridium Push-to-Talk in a Fully Transportable Case
-
Low Profile Dual-Mode Mag Antenna with 5m of Cable
-
Dedicated & Durable Corded Fist Mic
-
Standard DriveDock, so Can Support Iridium Extreme in Standard Voice Mode
-
Rugged, Easy-to-Carry Case
Rapidly Deployable Complete PTT Solution in an Easy Carry Case
The Beam Grab ‘N’ Go Corded Kits for Iridium Extreme® Push-To-Talk are a cost-effective PTT solution. The in-built DriveDOCK supports all features of the Iridium Extreme PTT service complete with a high-quality speaker and microphone making it ideal for a range of applications. Available in either a small or large case depending on application.
Easy to Use & Carry PTT Solution in a Hard Protected Case
Beam Grab ‘N’ Go Corded solution for Iridium Extreme PTT provides clear and improved PTT audio quality via the loudspeaker in the corded handset. The Grab ‘N’ Go Corded Kit supports the Iridium Extreme handset in either PTT or telephony mode. In standard voice mode, the Beam DriveDock will support all the services available on the Iridium Extreme.
- PTT & Voice Calling
-
Can be easily switched between PTT and Voice mode for greater flexibility and gaining access to the enhanced features available in voice mode, like SMS and Bluetooth
- Integrated Iridium &: GPS Antenna
-
With a high-quality dual mode Iridium / GPS antenna with 5m of deployable cable, making set up easy and quick in any situation
- All-Weather Resistant Case
-
Weather-proof design allows for the case to be used multiple environments and for a variety of applications and keeps all the equipment inside protected
- Industry Tested Fist Mic
-
With a high-quality fist mic giving both excellent voice quality and volume, along with great reliability in harsh environment
- AC / DC Power Capabilities
-
Flexible power solutions for various applications with either DC power connection or AC power connection to support various applications
Product Specifications and Certifications
| Mechanical | |
|---|---|
| Dimensions (L x W x H) | 401mm x 307mm x 173mm |
| Environmental | |
| Operating Temperature Range | -30 to +70 ℃ |
| Operating Humidity Range | <85 % RH |
| Storage Temperature Range | -35 to +85 ℃ |
| Antenna | |
| Antenna Design | Iridium and GPS |
| Type | Dual Mode Magnetic Mount |
| RF Interface | |
| Frequency Range | 1616 – 1626.5 MHz |
| Power | |
| Power Supply | AC/DC Power Supply |
| Input Voltage Range | 9-32 VDC |
| Maximal Current | 700 mA |
| Maximal Power | 8.4 W |
| Idle Current Average | 70 average mA |
| Idle Current Peak | 70 peak mA |
| Idle Power | 0.84 W |
| Network | |
| Satellite Coverage | 1616 – 1626MHz |
